Chemical compatibility is one of the most important factors in dosing pump installation. Even a perfectly sized and correctly installed dosing pump can fail prematurely if its materials are not compatible with the chemical being dosed. Incorrect compatibility causes corrosion, swelling, cracking, reduced dosing accuracy, and total pump breakdown.
This guide explains what technicians must check before selecting or installing a dosing pump for applications such as RO antiscalant dosing, chlorine injection, pH control, wastewater treatment, and industrial chemical handling.

1. Understand the Chemical Being Dosed
Proper chemical compatibility starts with identifying the exact chemical properties.
1.1 Chemical Type
Different chemicals require different materials. Common dosing chemicals include:

• Sodium hypochlorite (chlorine)
• Antiscalants
• Hydrochloric acid
• Sulfuric acid
• Caustic soda (NaOH)
• Coagulants (alum, PAC)
• Biocides
• Corrosion inhibitors

1.2 Chemical Concentration
Higher concentrations increase the aggressiveness of the chemical, requiring more resistant materials.
1.3 Temperature
Chemical reaction rates double with every 10°C increase. Hot climates such as the UAE accelerate corrosion, especially for chlorine and acids.

2. Check Pump Head Material Compatibility
The pump head is the first point of contact with the chemical.
Common Pump Head Materials

• PVC
• PP (Polypropylene)
• PVDF
• SS316
• Acrylic

Compatibility Guidelines

• PVC: Suitable for chlorine, coagulants, and low-concentration chemicals
• PP: Good for general water treatment chemicals
• PVDF: Ideal for acids, caustic, solvents, and high-concentration chemicals
• SS316: Used for industrial solvents and high-temperature fluids

Incorrect pump head material leads to:

• Cracking
• Swelling
• Stress corrosion
• Chemical leakage

3. Verify Diaphragm Material Compatibility
The diaphragm is responsible for creating dosing pressure. Its chemical resistance determines the pump’s lifespan.
Common Diaphragm Materials

• PTFE (Teflon)
• EPDM
• FKM (Viton)
• NBR

Best Practices

• PTFE: Most universal, resistant to acids, alkalis, oxidizers
• EPDM: Good for low-concentration chemicals but not for oils
• FKM: Excellent for solvents and aggressive media
• NBR: Suitable for oils and hydrocarbons

A wrong diaphragm material can cause:

• Swelling
• Tears and rupture
• Reduced dosing accuracy
• Safety hazards

4. Check Valve Materials (Seats, Balls, and O-Rings)
Valves determine suction and discharge reliability. Their materials must match the chemical’s corrosion potential.
Valve Seat Materials

• PTFE
• Ceramic
• SS316
• PVDF

O-Ring Materials

• FKM (Viton)
• EPDM
• PTFE-coated elastomers
• NBR

Common Mistakes

• Dosing chlorine with Viton O-rings (leads to hardening and cracking)
• Using SS316 in acidic dosing (causes pitting corrosion)

Correct valve selection reduces air-locking, leakage, and dosing fluctuations.

5. Evaluate Tubing and Piping Material
Tubing must withstand both chemical concentration and pressure.
Common Tubing Materials

• PVC
• HDPE
• PTFE / Teflon
• PVDF
• Stainless steel

Selection Guidelines

• Use PTFE/PVDF for acids and caustics
• Use PVC for chlorine, antiscalants, coagulants
• Avoid standard rubber hoses for aggressive chemicals
• Use stainless steel only for compatible, non-corrosive chemicals

Tubing failure can lead to leaks, air entry, and inconsistent dosing.

6. Consider Temperature, UV, and Environmental Factors
6.1 High Temperature
Chemicals react faster and degrade pump materials more quickly.
In the UAE, outdoor installations often exceed 45°C. Ensure:

• UV-protected tubing
• Heat-resistant diaphragm and seals
• Pump placed away from direct sunlight

6.2 Chemical Evaporation
Chlorine and acids evaporate faster at high temperature, requiring sealed tanks and compatible gaskets.
6.3 Humidity
High humidity accelerates external corrosion on metallic parts.

7. Understand Chemical Interactions with Other System Components
Chemical compatibility is not limited to the pump—it includes everything in contact with the chemical.
7.1 Chemical Tanks

• Use PE, HDPE, PP, or FRP tanks
• Avoid mild steel tanks for any chemical dosing

7.2 Injection Quills
Material must match the chemical to avoid cracking or pitting.
7.3 Calibration Cylinders
Ensure the calibration cylinder material is compatible with the chemical (typically acrylic or PVDF).

8. Check for Chemical Crystallization or Precipitation Issues
Some chemicals tend to crystallize or form deposits.
Examples

• Sodium hypochlorite forms salt crystals
• Alum and PAC produce sediment
• Caustic soda solidifies in cold weather
• Acids react with calcium deposits

Best Practices

• Use flush points to clean the lines
• Select oversized valves for crystallizing chemicals
• Use PTFE tubing to reduce blockage

9. Follow Manufacturer Compatibility Charts
All major dosing pump manufacturers (Grundfos, Ebara, Etatron, Milton Roy, Doseuro, SEKO) publish detailed compatibility charts.
What to Check

• Pump head
• Diaphragm
• Valve materials
• Tubing
• Fittings
• O-rings

Always verify compatibility before installation to avoid warranty issues and premature pump failure.

10. Conduct a Chemical Compatibility Review Before Installation
Before installing the pump, review the following:

• Chemical name and concentration
• Material compatibility for all wetted parts
• System temperature
• Expected dosing pressure
• Installation environment
• Chemical storage conditions
• Possibility of fumes affecting pump housing

This review helps prevent corrosion, leakage, and unexpected downtime.
Chemical compatibility is a critical factor in dosing pump installation. Selecting the right materials for the pump head, diaphragm, valves, O-rings, and tubing ensures safety, accuracy, and long-term reliability. Failure to check compatibility can result in corrosion, system damage, inaccurate dosing, and costly downtime—especially in harsh environments like the UAE. For more info contact Dosing Pump Suppliers in UAE or call us at +971 4 2522966.
